Size comparison · drawn to scale
Lada XRay vs Lifan X50: size comparison
- Length XRay 65 mm3 in longer
- Width XRay 43 mm2 in wider
- Height XRay 32 mm1 in taller
- Boot X50 194 L6.9 cu ft more
Car 1 blue, solid outline
Car 2 coral, dashed outline
Change cars
Zoom in to read the measurements — or see the table below.
Scale about 1:20 on a desktop screen · grid 500 mm1 ft · in Overlay both cars start at the front bumper Side view: dashed lines mark the axles · wheelbase estimated where unknown Front view: width without mirrors Top view: footprint on the road
Dimensions and difference
The XRay is 65 mm3 in longer, 43 mm2 in wider and 32 mm1 in taller than the X50.
| Dimension | XRay | X50 | Difference, car 1 vs car 2 |
|---|---|---|---|
| Length | 4,165 mm13 ft 8 in13 ft 8 in4,165 mm | 4,100 mm13 ft 5 in13 ft 5 in4,100 mm | +65 mm+3 in +1.6% |
| Width | 1,765 mm5 ft 9 in5 ft 9 in1,765 mm | 1,722 mm5 ft 8 in5 ft 8 in1,722 mm | +43 mm+2 in +2.5% |
| Height | 1,572 mm5 ft 2 in5 ft 2 in1,572 mm | 1,540 mm5 ft 1 in5 ft 1 in1,540 mm | +32 mm+1 in +2.1% |
| Wheelbase | 2,593 mm8 ft 6 in8 ft 6 in2,593 mm | Not in our catalog yet | — |
| Footprint | 7.35 m²79.1 sq ft79.1 sq ft7.35 m² | 7.06 m²76.0 sq ft76.0 sq ft7.06 m² | +0.29 m²+3.1 sq ft +4.1% |
| Boot | 376 L13.3 cu ft13.3 cu ft376 L | 570 L20.1 cu ft20.1 cu ft570 L | −194 L−6.9 cu ft −34.0% |
Width without mirrors. Figures come from the catalog version pages; the drawing uses the same numbers. Body outlines are generic for the body type — proportions are exact, styling is not.
Garage and parking
A typical single garage is about 5.5 × 3.0 m18 ft 1 in × 9 ft 10 in inside; a parking bay about 5.0 × 2.5 m16 ft 5 in × 8 ft 2 in. Room to open a door: about 600 mm2 ft each side.
XRay
- Single garage
- Fits 1,335 mm4 ft 5 in to spare in length, 618 mm2 ft 0 in each side
- Parking bay
- Tight 835 mm2 ft 9 in to spare in length, 368 mm1 ft 2 in each side
X50
- Single garage
- Fits 1,400 mm4 ft 7 in to spare in length, 639 mm2 ft 1 in each side
- Parking bay
- Tight 900 mm2 ft 11 in to spare in length, 389 mm1 ft 3 in each side
Frequently asked questions
Which is bigger, the Lada XRay or the Lifan X50?
The Lada XRay is the bigger car by footprint (length × width). The XRay is 65 mm longer, 43 mm wider and 32 mm taller than the X50.
Will the Lada XRay and the Lifan X50 fit in a standard garage?
In a typical single garage of 5.5 × 3.0 m inside: The Lada XRay fits with room to open the doors (1,335 mm to spare in length, 618 mm each side). The Lifan X50 fits with room to open the doors (1,400 mm to spare in length, 639 mm each side). Widths are without mirrors; check your own garage with our garage checker.
Which has the bigger boot?
The Lifan X50: 570 L against 376 L in the Lada XRay (seats up, as quoted by the maker).
Drawn to one scale
Both cars use the same millimetre grid, so a longer bonnet or a taller roof shows exactly as it is.
Wheels at the real wheelbase
Dashed lines mark the axles. In Overlay both cars start at the front bumper; car 2 has a dashed outline.
Will it fit my garage?
Switch to Top view, or to feet and inches if your garage plan is in feet. Allow about 600 mm (2 ft) for opening the doors.
