Size comparison · drawn to scale
Nissan Patrol Y63 vs Toyota Land Cruiser J200: size comparison
- Length Patrol Y63 360 mm1 ft 2 in longer
- Width Patrol Y63 50 mm2 in wider
- Height Land Cruiser J200 25 mm1 in taller
Car 1 blue, solid outline
Car 2 coral, dashed outline
Change cars
Zoom in to read the measurements — or see the table below.
Scale about 1:26 on a desktop screen · grid 500 mm1 ft · in Overlay both cars start at the front bumper Side view: dashed lines mark the axles Front view: width without mirrors Top view: footprint on the road
Dimensions and difference
The Patrol Y63 is 360 mm1 ft 2 in longer, 50 mm2 in wider and 25 mm1 in lower than the Land Cruiser J200. Its wheelbase is 225 mm9 in longer.
| Dimension | Patrol Y63 | Land Cruiser J200 | Difference, car 1 vs car 2 |
|---|---|---|---|
| Length | 5,350 mm17 ft 7 in17 ft 7 in5,350 mm | 4,990 mm16 ft 4 in16 ft 4 in4,990 mm | +360 mm+1 ft 2 in +7.2% |
| Width | 2,030 mm6 ft 8 in6 ft 8 in2,030 mm | 1,980 mm6 ft 6 in6 ft 6 in1,980 mm | +50 mm+2 in +2.5% |
| Height | 1,945 mm6 ft 5 in6 ft 5 in1,945 mm | 1,970 mm6 ft 6 in6 ft 6 in1,970 mm | −25 mm−1 in −1.3% |
| Wheelbase | 3,075 mm10 ft 1 in10 ft 1 in3,075 mm | 2,850 mm9 ft 4 in9 ft 4 in2,850 mm | +225 mm+9 in +7.9% |
| Footprint | 10.86 m²116.9 sq ft116.9 sq ft10.86 m² | 9.88 m²106.3 sq ft106.3 sq ft9.88 m² | +0.98 m²+10.6 sq ft +9.9% |
| Boot | Not in our catalog yet | 655 L23.1 cu ft23.1 cu ft655 L | — |
| Kerb weight | 2,680 kg5,908 lb5,908 lb2,680 kg | 2,581 kg5,690 lb5,690 lb2,581 kg | +99 kg+218 lb +3.8% |
Width without mirrors. Figures come from the catalog version pages; the drawing uses the same numbers. Body outlines are generic for the body type — proportions are exact, styling is not.
Garage and parking
A typical single garage is about 5.5 × 3.0 m18 ft 1 in × 9 ft 10 in inside; a parking bay about 5.0 × 2.5 m16 ft 5 in × 8 ft 2 in. Room to open a door: about 600 mm2 ft each side.
Patrol Y63
- Single garage
- Tight 150 mm6 in to spare in length, 485 mm1 ft 7 in each side
- Parking bay
- Does not fit 350 mm1 ft 2 in too long
Land Cruiser J200
- Single garage
- Tight 510 mm1 ft 8 in to spare in length, 510 mm1 ft 8 in each side
- Parking bay
- Tight 10 mm0.4 in to spare in length, 260 mm10 in each side
Frequently asked questions
Which is bigger, the Nissan Patrol Y63 or the Toyota Land Cruiser J200?
The Nissan Patrol Y63 is the bigger car by footprint (length × width). The Patrol Y63 is 360 mm longer, 50 mm wider and 25 mm lower than the Land Cruiser J200. Its wheelbase is 225 mm longer.
Will the Nissan Patrol Y63 and the Toyota Land Cruiser J200 fit in a standard garage?
In a typical single garage of 5.5 × 3.0 m inside: The Nissan Patrol Y63 fits, but it is tight to get out (150 mm to spare in length, 485 mm each side). The Toyota Land Cruiser J200 fits, but it is tight to get out (510 mm to spare in length, 510 mm each side). Widths are without mirrors; check your own garage with our garage checker.
Drawn to one scale
Both cars use the same millimetre grid, so a longer bonnet or a taller roof shows exactly as it is.
Wheels at the real wheelbase
Dashed lines mark the axles. In Overlay both cars start at the front bumper; car 2 has a dashed outline.
Will it fit my garage?
Switch to Top view, or to feet and inches if your garage plan is in feet. Allow about 600 mm (2 ft) for opening the doors.
