Size comparison · drawn to scale
Mitsubishi ASX I vs Opel Mokka: size comparison
- Length ASX I 17 mm0.7 in longer
- Width About the same width
- Height Mokka 21 mm0.8 in taller
- Boot ASX I 59 L2.1 cu ft more
Car 1 blue, solid outline
Car 2 coral, dashed outline
Change cars
Zoom in to read the measurements — or see the table below.
Scale about 1:21 on a desktop screen · grid 500 mm1 ft · in Overlay both cars start at the front bumper Side view: dashed lines mark the axles Front view: width without mirrors Top view: footprint on the road
Dimensions and difference
The ASX I is 17 mm0.7 in longer, 7 mm0.3 in narrower and 21 mm0.8 in lower than the Mokka. Its wheelbase is 115 mm5 in longer.
| Dimension | ASX I | Mokka | Difference, car 1 vs car 2 |
|---|---|---|---|
| Length | 4,295 mm14 ft 1 in14 ft 1 in4,295 mm | 4,278 mm14 ft 0 in14 ft 0 in4,278 mm | +17 mm+0.7 in +0.4% |
| Width | 1,770 mm5 ft 10 in5 ft 10 in1,770 mm | 1,777 mm5 ft 10 in5 ft 10 in1,777 mm | −7 mm−0.3 in −0.4% |
| Height | 1,625 mm5 ft 4 in5 ft 4 in1,625 mm | 1,646 mm5 ft 5 in5 ft 5 in1,646 mm | −21 mm−0.8 in −1.3% |
| Wheelbase | 2,670 mm8 ft 9 in8 ft 9 in2,670 mm | 2,555 mm8 ft 5 in8 ft 5 in2,555 mm | +115 mm+5 in +4.5% |
| Footprint | 7.60 m²81.8 sq ft81.8 sq ft7.60 m² | 7.60 m²81.8 sq ft81.8 sq ft7.60 m² | Same |
| Boot | 415 L14.7 cu ft14.7 cu ft415 L | 356 L12.6 cu ft12.6 cu ft356 L | +59 L+2.1 cu ft +16.6% |
Width without mirrors. Figures come from the catalog version pages; the drawing uses the same numbers. Body outlines are generic for the body type — proportions are exact, styling is not.
Garage and parking
A typical single garage is about 5.5 × 3.0 m18 ft 1 in × 9 ft 10 in inside; a parking bay about 5.0 × 2.5 m16 ft 5 in × 8 ft 2 in. Room to open a door: about 600 mm2 ft each side.
ASX I
- Single garage
- Fits 1,205 mm3 ft 11 in to spare in length, 615 mm2 ft 0 in each side
- Parking bay
- Tight 705 mm2 ft 4 in to spare in length, 365 mm1 ft 2 in each side
Mokka
- Single garage
- Fits 1,222 mm4 ft 0 in to spare in length, 612 mm2 ft 0 in each side
- Parking bay
- Tight 722 mm2 ft 4 in to spare in length, 362 mm1 ft 2 in each side
Frequently asked questions
Which is bigger, the Mitsubishi ASX I or the Opel Mokka?
The Mitsubishi ASX I is the bigger car by footprint (length × width). The ASX I is 17 mm longer, 7 mm narrower and 21 mm lower than the Mokka. Its wheelbase is 115 mm longer.
Will the Mitsubishi ASX I and the Opel Mokka fit in a standard garage?
In a typical single garage of 5.5 × 3.0 m inside: The Mitsubishi ASX I fits with room to open the doors (1,205 mm to spare in length, 615 mm each side). The Opel Mokka fits with room to open the doors (1,222 mm to spare in length, 612 mm each side). Widths are without mirrors; check your own garage with our garage checker.
Which has the bigger boot?
The Mitsubishi ASX I: 415 L against 356 L in the Opel Mokka (seats up, as quoted by the maker).
Drawn to one scale
Both cars use the same millimetre grid, so a longer bonnet or a taller roof shows exactly as it is.
Wheels at the real wheelbase
Dashed lines mark the axles. In Overlay both cars start at the front bumper; car 2 has a dashed outline.
Will it fit my garage?
Switch to Top view, or to feet and inches if your garage plan is in feet. Allow about 600 mm (2 ft) for opening the doors.
