Size comparison · drawn to scale
Kia Niro SG2 vs Toyota Prius XW60: size comparison
- Length Prius XW60 180 mm7 in longer
- Width Niro SG2 43 mm2 in wider
- Height Niro SG2 125 mm5 in taller
Car 1 blue, solid outline
Car 2 coral, dashed outline
Change cars
Zoom in to read the measurements — or see the table below.
Scale about 1:21 on a desktop screen · grid 500 mm1 ft · in Overlay both cars start at the front bumper Side view: dashed lines mark the axles · wheelbase estimated where unknown Front view: width without mirrors Top view: footprint on the road
Dimensions and difference
The Niro SG2 is 180 mm7 in shorter, 43 mm2 in wider and 125 mm5 in taller than the Prius XW60.
| Dimension | Niro SG2 | Prius XW60 | Difference, car 1 vs car 2 |
|---|---|---|---|
| Length | 4,420 mm14 ft 6 in14 ft 6 in4,420 mm | 4,600 mm15 ft 1 in15 ft 1 in4,600 mm | −180 mm−7 in −3.9% |
| Width | 1,825 mm6 ft 0 in6 ft 0 in1,825 mm | 1,782 mm5 ft 10 in5 ft 10 in1,782 mm | +43 mm+2 in +2.4% |
| Height | 1,545 mm5 ft 1 in5 ft 1 in1,545 mm | 1,420 mm4 ft 8 in4 ft 8 in1,420 mm | +125 mm+5 in +8.8% |
| Wheelbase | Not in our catalog yet | 2,750 mm9 ft 0 in9 ft 0 in2,750 mm | — |
| Footprint | 8.07 m²86.8 sq ft86.8 sq ft8.07 m² | 8.20 m²88.2 sq ft88.2 sq ft8.20 m² | −0.13 m²−1.4 sq ft −1.6% |
| Boot | 451 L15.9 cu ft15.9 cu ft451 L | Not in our catalog yet | — |
| Kerb weight | 1,474–1,739 kg3,250–3,834 lb3,250–3,834 lb1,474–1,739 kg | 1,620 kg3,571 lb3,571 lb1,620 kg | −146 kg−322 lb −9.0% |
Width without mirrors. Figures come from the catalog version pages; the drawing uses the same numbers. Body outlines are generic for the body type — proportions are exact, styling is not. Weight difference compares the lightest versions.
Garage and parking
A typical single garage is about 5.5 × 3.0 m18 ft 1 in × 9 ft 10 in inside; a parking bay about 5.0 × 2.5 m16 ft 5 in × 8 ft 2 in. Room to open a door: about 600 mm2 ft each side.
Niro SG2
- Single garage
- Tight 1,080 mm3 ft 7 in to spare in length, 588 mm1 ft 11 in each side
- Parking bay
- Tight 580 mm1 ft 11 in to spare in length, 338 mm1 ft 1 in each side
Prius XW60
- Single garage
- Fits 900 mm2 ft 11 in to spare in length, 609 mm2 ft 0 in each side
- Parking bay
- Tight 400 mm1 ft 4 in to spare in length, 359 mm1 ft 2 in each side
Frequently asked questions
Which is bigger, the Kia Niro SG2 or the Toyota Prius XW60?
The Toyota Prius XW60 is the bigger car by footprint (length × width). The Niro SG2 is 180 mm shorter, 43 mm wider and 125 mm taller than the Prius XW60.
Will the Kia Niro SG2 and the Toyota Prius XW60 fit in a standard garage?
In a typical single garage of 5.5 × 3.0 m inside: The Kia Niro SG2 fits, but it is tight to get out (1,080 mm to spare in length, 588 mm each side). The Toyota Prius XW60 fits with room to open the doors (900 mm to spare in length, 609 mm each side). Widths are without mirrors; check your own garage with our garage checker.
Drawn to one scale
Both cars use the same millimetre grid, so a longer bonnet or a taller roof shows exactly as it is.
Wheels at the real wheelbase
Dashed lines mark the axles. In Overlay both cars start at the front bumper; car 2 has a dashed outline.
Will it fit my garage?
Switch to Top view, or to feet and inches if your garage plan is in feet. Allow about 600 mm (2 ft) for opening the doors.
