Size comparison · drawn to scale
Brilliance V5 vs Haima 7: size comparison
- Length V5 199 mm8 in longer
- Width V5 92 mm4 in wider
- Height 7 13 mm0.5 in taller
Car 1 blue, solid outline
Car 2 coral, dashed outline
Change cars
Zoom in to read the measurements — or see the table below.
Scale about 1:23 on a desktop screen · grid 500 mm1 ft · in Overlay both cars start at the front bumper Side view: dashed lines mark the axles Front view: width without mirrors Top view: footprint on the road
Dimensions and difference
The V5 is 199 mm8 in longer, 92 mm4 in wider and 13 mm0.5 in lower than the 7. Its wheelbase is 106 mm4 in longer.
| Dimension | V5 | 7 | Difference, car 1 vs car 2 |
|---|---|---|---|
| Length | 4,620 mm15 ft 2 in15 ft 2 in4,620 mm | 4,421 mm14 ft 6 in14 ft 6 in4,421 mm | +199 mm+8 in +4.5% |
| Width | 1,922 mm6 ft 4 in6 ft 4 in1,922 mm | 1,830 mm6 ft 0 in6 ft 0 in1,830 mm | +92 mm+4 in +5.0% |
| Height | 1,727 mm5 ft 8 in5 ft 8 in1,727 mm | 1,740 mm5 ft 9 in5 ft 9 in1,740 mm | −13 mm−0.5 in −0.7% |
| Wheelbase | 2,725 mm8 ft 11 in8 ft 11 in2,725 mm | 2,619 mm8 ft 7 in8 ft 7 in2,619 mm | +106 mm+4 in +4.0% |
| Footprint | 8.88 m²95.6 sq ft95.6 sq ft8.88 m² | 8.09 m²87.1 sq ft87.1 sq ft8.09 m² | +0.79 m²+8.5 sq ft +9.8% |
| Boot | 430 L15.2 cu ft15.2 cu ft430 L | Not in our catalog yet | — |
| Kerb weight | Not in our catalog yet | 1,500 kg3,307 lb3,307 lb1,500 kg | — |
Width without mirrors. Figures come from the catalog version pages; the drawing uses the same numbers. Body outlines are generic for the body type — proportions are exact, styling is not.
Garage and parking
A typical single garage is about 5.5 × 3.0 m18 ft 1 in × 9 ft 10 in inside; a parking bay about 5.0 × 2.5 m16 ft 5 in × 8 ft 2 in. Room to open a door: about 600 mm2 ft each side.
V5
- Single garage
- Tight 880 mm2 ft 11 in to spare in length, 539 mm1 ft 9 in each side
- Parking bay
- Tight 380 mm1 ft 3 in to spare in length, 289 mm11 in each side
7
- Single garage
- Tight 1,079 mm3 ft 6 in to spare in length, 585 mm1 ft 11 in each side
- Parking bay
- Tight 579 mm1 ft 11 in to spare in length, 335 mm1 ft 1 in each side
Frequently asked questions
Which is bigger, the Brilliance V5 or the Haima 7?
The Brilliance V5 is the bigger car by footprint (length × width). The V5 is 199 mm longer, 92 mm wider and 13 mm lower than the 7. Its wheelbase is 106 mm longer.
Will the Brilliance V5 and the Haima 7 fit in a standard garage?
In a typical single garage of 5.5 × 3.0 m inside: The Brilliance V5 fits, but it is tight to get out (880 mm to spare in length, 539 mm each side). The Haima 7 fits, but it is tight to get out (1,079 mm to spare in length, 585 mm each side). Widths are without mirrors; check your own garage with our garage checker.
Drawn to one scale
Both cars use the same millimetre grid, so a longer bonnet or a taller roof shows exactly as it is.
Wheels at the real wheelbase
Dashed lines mark the axles. In Overlay both cars start at the front bumper; car 2 has a dashed outline.
Will it fit my garage?
Switch to Top view, or to feet and inches if your garage plan is in feet. Allow about 600 mm (2 ft) for opening the doors.
