Toyota RAV4 XA40 2.0 SUV
107 kW145 PS143 hp2012–2018
Read the full story of the Toyota RAV4 XA40
Updated Report an error
- Power
- 107 kW 145 PS · 143 hp
- Kerb weight
- 1,610 kg
- Boot volume
- 506 l
- Length
- 4,570 mm
Under the bonnet of the Toyota RAV4 XA40 2.0 petrol SUV sits a 2.0-litre four-cylinder petrol engine, good for 107 kW (145 PS). In the RAV4 XA40 2.0 petrol, power goes to all four wheels.
Of the 3 versions in the RAV4 XA40 line-up, the RAV4 XA40 2.0 petrol is the entry version — the 2.5 (132 kW) delivers 23% more. In figures, it tips the scales at 1,610 kg and offers 90 PS per tonne. To see how it measures up, compare the RAV4 XA40 2.0 petrol with the Nissan X-Trail or the Mitsubishi Outlander.
Dimensions drawing
To scale · width without mirrors
Zoom in to read the measurements — or see the table below.
grid 500 mm1 ft Side view: dashed lines mark the axles
Engine
| Fuel | Petrol |
|---|---|
| Displacement | 2,000 cm³ 2.0 l · 122 cu in |
| Cylinders | 4 |
| Power | 107 kW 145 PS · 143 hp |
| Drive | All-wheel drive |
Dimensions and weight
| Length | 4,570 mm 179.9 in |
|---|---|
| Width | 1,845 mm 72.6 in |
| Height | 1,670 mm 65.7 in |
| Wheelbase | 2,660 mm 104.7 in |
| Kerb weight | 1,610 kg 3,549 lb |
| Boot volume | 506 l 17.9 cu ft |
Production
| Body type | SUV |
|---|---|
| Years | 2012–2018 |
| Generation | RAV4 XA40 (2012–2018) |
Compare size All RAV4 XA40 versions All Toyota spec sheets
Data sources
Data checked by an editor against the sources below.
Data: 12 of 25 fields · 2 sources · data changed 23 Oct 2026
