KamAZ-6520 11.8 Dump truck 16-sp manual
294 kW400 PS394 hp1,766 Nm2002
Read the full story of the KamAZ-6520
Updated Report an error
- Power
- 294 kW 400 PS · 394 hp
- Torque
- 1,766 Nm 1,303 lb-ft
- Kerb weight
- 12,950 kg
- Top speed
- 90 km/h
Built 2002, the KamAZ-6520 11.8 740.63-400 diesel dump truck develops 294 kW (400 PS) and 1,766 Nm of torque from an 11.8-litre diesel engine. The KamAZ-6520 11.8 740.63-400 diesel is paired with a 16-speed manual gearbox.
Among the 2 KamAZ-6520 (2002) versions, the KamAZ-6520 11.8 740.63-400 diesel is the strongest on torque (1,766 Nm). According to our catalog data, the KamAZ-6520 11.8 740.63-400 diesel reaches 90 km/h, weighs 12,950 kg and has 31 PS per tonne to work with.
Engine
| Engine code | 740.63-400 |
|---|---|
| Fuel | Diesel |
| Displacement | 11,760 cm³ 11.8 l · 718 cu in |
| Power | 294 kW 400 PS · 394 hp |
| Torque | 1,766 Nm 1,303 lb-ft |
Transmission
| Gearbox | Manual |
|---|---|
| Gears | 16 |
Performance
| Top speed | 90 km/h 56 mph |
|---|
Dimensions and weight
| Kerb weight | 12,950 kg 28,550 lb |
|---|---|
| Fuel tank | 350 l 92.5 US gal |
Production
| Body type | Dump truck |
|---|---|
| Years | 2002 |
| Generation | KamAZ-6520 (2002) |
KamAZ 740.63-400 engine All KamAZ-6520 versions All KamAZ spec sheets
